Biobank Series
Share：
Biobank series for large scale storage is designed to ensure the maximum storage capacity with the minimum consumption of liquid nitrogen to lower the overall cost of operation .
Product Features
Large Scale Storage Capacities from 13,000 to 94,875 x Standard 2ml Cryovials
Vapour Phase Storage to Prevent Cross Contamination
Excellent Temperature Uniformity
One-Touch Defogging for Easier Access
Liquid Nitrogen Splash-Proof Feature Provides Safer Operation
Blood Bag Storage Options Available
Specifications
| Model | Volume of LN2 (L) | 2ml Volume | Inside Neck Diameter (mm) | Operating Height (mm) | Volume of LN2(L) |
| YDD-1000-465 | 1014 | 51000 | 465mm | 1090 | |
| YDD-1300-635 | 1340 | 58500 | 635mm | 997 | |
| YDD-1600-635 | 1660 | 76050 | 635mm | 967 | |
| YDD-1800-635 | 1880 | 94875 | 635mm | 1097 | |
| YDD-350-326 | 13000 | 326mm | 1263 | 350L | |
| YDD-370-326 | 15600 | 326mm | 1096 | 370L | |
| YDD-450-326 | 21000 | 326mm | 1212 | 460L | |
| YDD-550-445 | 27000 | 445mm | 970 | 587L | |
| YDD-750-445 | 37800 | 445mm | 995 | 783L | |
| YDD-850-465 | 42900 | 465mm | 980 | 890L |
